蜂鸣器 BMC1265

零件应在一个条件下（温度：5～35℃，湿度：45%～85%R.H.，大气压：860～1060hPa）进行测量，除非调节标准条件（温度：25±3℃，湿度为60±10%R.H.大气压：860~1060hPa）来进行测量。

1、测试条件产品测试条件：温度：5～35℃，湿度：45%～85%R.H.，气压：860～1060hPa。标准测试条件：温度：25±3℃,湿度：60±10%R.H. 气压：860～1060hPa1额定电压5VDC2工作电压4-7VDC3额定电流Max.30mA,at5VDC4输出音压Min.82dB,at5VDC5谐振频率2700±300Hz6音调Continuous7工作温度(℃)-20℃～+70

所属分类：电磁有源蜂鸣器

在线留言

关键词：蜂鸣器 | 喇叭| 物化片

产品描述

1.Technical Parameter
Measuring condition

Part shall be measured under a condition (Temperature: 5～35℃, Humidity: 45% ～ 85%R.H., Atmospheric pressure: 860 ～ 1060hPa) unless the standard condition (Temperature: 25±3℃, Humidity: 60±10%R.H. Atmospheric pressure: 860 ～1060hPa) is regulated to measure.

1	Rated Voltage	5Vo-p
2	Operating Voltage	3-7VDC
3	Rated Current	Max.30mA, at 5VDC
4	Sound Output at 10cm	Min.85dB, at 5VDC
5	Tone	Continuous
6	Resonant Frequency	2700±300 Hz
7	Operating Temperature	-20- +70℃
8	Store Temperature	-30 - +80℃
9	Net Weight	Approx 1.5g
10	RoHS	Yes

2.Dimensions Unit: mm

*Unit: mm; Tolerance: ±0.5mm Except Specified
*Housing Material: Black PBT

3. Electrical And Acoustical Measuring Condition

Recommended Test Circuit

Recommended Setting

4.Reliability Test

After any following tests the part shall meet specifications without any degradation in appearance and performance except SPL. SPL shall not deviate more than -10 dB from the initial value
a)Ordinary Temperature Life Test
The part shall be subjected to 96 hours at 25±10℃. Input rated voltage Resonant frequency, 1/2 duty Square wave.
b)High Temperature Test
The part shall be capable of with standing a storage temperature of +85℃ for 96 hours.
c)Low Temperature Test
The part shall be capable of with standing a storage temperature of -40℃ for 96 hours.
d)Humidity Test
Temperature:+40℃±3℃ Relative Humidity:90%～95% Duration: 48 hours and expose to room temperature for 6 hours
e)Temperature Shock Test
Temperature:60℃ /1hour→ 25℃/3hours→-20℃/1hour→ 25℃/3hours (1cycle) Total cycle: 10 cycles
f)Drop Test
Standard Packaging From 75cm(Drop on hard wood or board of 5cm thick, three sides, six plain.)
g)Vibration Test

Vibration:1000cycles /min. Amplitude:1.5mm, Duration: 1 hour in each 3 axes

Note:

As this product is not protected from foreign material entering, please make sure that any foreign materials (e.g. magnetic powder, washing solvent, flux, corrosive gas) do not enter this product in your production processes. The functional degradation (e.g. SPL down) may occur if foreign material enter it.

5.Packing

包装要求

12型泡沫盒，泡沫料号：F6-712，1000pcs一堆；5堆/箱；5000pcs/箱
外箱料号：F6-003；外箱尺寸50*41*25cm

唛头要求

内盒：

按客户订单

外箱：

按客户订单
